Descriptions
Scan Technology:Â 2D Imager
Image sensor:Â CMOS
light source:Â RED LED 610-650nm
CPU:Â 32bit ARM
COMS resolution:Â 640×480 Pixels
Exposure:Â Global Shutter
Scanning speed:Â 60 fps
Minmum resolution: ≥3mil
Decoding depth of field:Â 60-360mm (13mil PCS90%)
Scanning angle: rotate 360°, inclination 65°, elevation 60°
System supported:Â Android/Windows/Linux/IOS
Scan mode:Â Manual trigger & Automatic induction
Decoding capability:Â 1D: Codabar, Code11, Code 39, Code32, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code93, Code 128, GS1-128, UPC-A, UPC-E, EAN 8, EAN 13, GS1 DataBar (RSS14), GS1 DataBar Limited, GS1 DataBar Expanded, etc 2D: PDF417, Micro PDF417, QR Code, Micro QR, Data Matrix, Aztec Code
Size:Â Scanner: L*W*H= 163*68*80(mm),Charging base: L*W*H=15*6*19(mm)
Weight:Â Scanner: 175g
Interface:Â USB
Charging way:Â Micro USB cable charging
Charging time:Â 4.5H
Standby time:Â 6 months(Dormant state)
Continuous battery life:Â 16H
Battery:Â Replaceable & Rechargeable lithium battery, 2200mAh
Receiver interface:Â USB
Material:Â ABS+TPU
Input voltage:Â DC 5V
Working current:Â 250mah
Stand-by current:Â 1uA
Indicator:Â LED indicator light, buzzer
Interface:Â Â USB/USB-VCP
Communication methods:Â 2.4G wireless communication, Bluetooth wireless communication
Communication distance:Â 2.4G mode: 100M (open space), Bluetooth mode: 10M (open space)
IP Standard:Â IP54
Drop Resistance:Â 1.5m
Temperature (Operating): -0°C~50°C
Humidity (Operating):Â Relative humidity 5%~95% (no condensation)
Temperature (Storage): -40°C~70°C
Light source:Â 0-5000Lux(fluorescent), 0~100,000 Lux(Sunlight)
