Sunlux XL-9600 2D Wireless Barcode Scanner

Descriptions

Scan Technology: 2D Imager
Image sensor: CMOS
light source: RED LED 610-650nm
CPU: 32bit ARM
COMS resolution: 640×480 Pixels
Exposure: Global Shutter
Scanning speed: 60 fps
Minmum resolution: ≥3mil
Decoding depth of field: 60-360mm (13mil PCS90%)
Scanning angle: rotate 360°, inclination 65°, elevation 60°
System supported: Android/Windows/Linux/IOS
Scan mode: Manual trigger & Automatic induction
Decoding capability: 1D: Codabar, Code11, Code 39, Code32, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code93, Code 128, GS1-128, UPC-A, UPC-E, EAN 8, EAN 13, GS1 DataBar (RSS14), GS1 DataBar Limited, GS1 DataBar Expanded, etc 2D: PDF417, Micro PDF417, QR Code, Micro QR, Data Matrix, Aztec Code

Size: Scanner: L*W*H= 163*68*80(mm),Charging base: L*W*H=15*6*19(mm)
Weight: Scanner: 175g
Interface: USB
Charging way: Micro USB cable charging
Charging time: 4.5H
Standby time: 6 months(Dormant state)
Continuous battery life: 16H
Battery: Replaceable & Rechargeable lithium battery, 2200mAh
Receiver interface: USB
Material: ABS+TPU
Input voltage: DC 5V
Working current: 250mah
Stand-by current: 1uA
Indicator: LED indicator light, buzzer
Interface:  USB/USB-VCP

Communication methods: 2.4G wireless communication, Bluetooth wireless communication
Communication distance: 2.4G mode: 100M (open space), Bluetooth mode: 10M (open space)
IP Standard: IP54
Drop Resistance: 1.5m
Temperature (Operating): -0°C~50°C
Humidity (Operating): Relative humidity 5%~95% (no condensation)
Temperature (Storage): -40°C~70°C
Light source: 0-5000Lux(fluorescent), 0~100,000 Lux(Sunlight)
